How to Flash Dell Venue 7 3740 with Fastboot and solve logo probleme

How to Flash Dell Venue 7 3740 with Fastboot and solve logo probleme Prerequisite System Setup: xFSTK_downloader_1.5.1 ... thumbnail 1 summary

How to Flash Dell Venue 7 3740 with Fastboot and solve logo probleme






Prerequisite System Setup:

xFSTK_downloader_1.5.1

P708T_Driver_V1.0.0

iSocUSB-Driver-Setup-1.0.4

IntelAndroidDrvSetup1.5.0

1. Download and Install Dell driver and the flashing tool

2. Download and extract tar package, YTD802A519500-2014-07-16-16.tgz

3. Open Flash Tool ''xFTSK-Dowloader'', and set configuration for each s dection 4. Select Firmware files as the following from SW Image directory:
FW DnX= dnx_fwr_PRQ.bin
IFWI= for_product_ifwi_PRQ.bin

OS DnX= dnx_osr_PRQ.bin
OS Image= droidboot.img.POS.bin
4. Power off the tablet device (long press power key for more than 15 seconds)

5. Click ''Begin Download'' in Flash Tool, it will display waiting time is 60 seconds

6. Long press the volume up button and then plug in the cable

7. When flash process started, then release the volume up button

8. When firmware flash is done, Flash Tool will show Success: FW+OS Download Completed!

9. After flashing firmware, the tablet device will switch to fastboot mode automatically

Tutorial Video :


How to Flash Dell Venue 7 3740 with Fastboot and solve logo probleme


Package Link





Firmware:  Download

Drivers:  Download

Fastboot CMD:  Download
How To:  Download
